FW30L Electric Sweeper

length(mm):4650
width(mm):1600
height(mm):2050
product details

Item

Unit

Specifications

Dimensions (L/W/H)

mm

4650×1600×2050

Axle distance

mm

2400

Front/rear overhang

mm

1000/1242

Approach angle/departure angle

°

27/13

Vehicle kerb weight

kg

2400

Maximum total weight

kg

3000

Maximum speed (fully loaded)

Km/h

25

Maximum gradient angle

°

20

Braking distance (fully loaded at 30 km/h)

m

≤6.5

Turning radius

m

5

Total volume of water tank

L

1000

Effective volume of garbage bin

L

1400

Maximum volume of garbage bin

L

2300

Cleaning width

m

2400

Operating speed

km/h

3-10(5-star Speed)

Maximum working efficiency

/h

24000

Rated power of driving motor

kW

7.5

Rated voltage of driving motor

V

72

Chassis model

/

LC30

Charging time

h

2 (DC fast charging) and 8-10 (AC slow charging)

Continuous operating time

h

4-6

Rated power of fan motor

kW

5

Width of suction nozzle

mm

700

Battery type

/

31.5 kWh lithium iron phosphate battery

Battery specifications

V/Ah

76.8/410
