FS21X Electric Multi-functional Cleaning Vehicle

length(mm):3700
width(mm):1200
height(mm):2885
product details

Item

Unit

Specifications

Dimensions (L/W/H)

mm

3700×1200×2885

Kerb weight of vehicle

kg

1900

Axle distance

mm

1580

Front wheel track

mm

866

Rear wheel track

mm

984

Minimum ground clearance

mm

150

Maximum total weight

kg

2500

Theoretical maximum speed

km/h

25

Maximum gradient

%

20

Braking distance (20 km/h)

m

6.5

Minimum turning diameter

m

4.5

Effective volume of water tank

L

800

Cleaning width

mm

1885

Motor power of upper equipment

kw

8

Single charging operation time

h

6-8

Drive form

/

Rear axle drive

Drive motor power

kw

7.5kw

Type of power battery

/

Lithium iron phosphate

Voltage of power battery (V)

v

76.8

Rated capacity of power battery

ah

334

Stored capacity of power battery

kWh

30.72

Gearshift method

/

Continuously variable transmission (CVT)

Structure

/

Hinge steering
